6745 kw Siemens SST-110 Steam Turbine Generator, Year 2018. Single Stage Back Pressure Turbine Design. Inlet Steam: 90,000 #/hr Steam at 850 PSI and 650 F. Exhaust Steam: 90,000 #/hr at 46 PSI and 375 F. Exhaust Steam Pressure is variable depending on process conditions. Includes: 8750 KVA AC Synchronous Generator Manufactured by TD Power Systems, Type TC150. Capacity: 7.0 MW / 13.8kV / 60 Hertz. Year 2018. System used less than one year due to complete plant closure. All controls and MCC panels are available. Desuperheater is available to control exhaust steam temperature. SPARE TURBINE ROTOR ASSEMBLY INCLUDED.
28 MW GE Steam Turbine Generator. 32.4 MVA / 60 Hertz / 13.8 kV. New Steam Path 2007 Generator rewind in 2007 with GE Micapal winding insulation. Mark V Governor installed year 2000. Designed for 680000 PPH steam at the inlet with two (2) extraction points at 150 PSI and 60 PSI and the balance of steam is condensed. Includes all auxiliaries except excitor. Originally manufactured 1968. Well maintained with any available spares included.
One (1) used 1000 KW Elliott Steam Turbine Generators Rebuilt Quantity of Two (2) available. Back Pressure Steam Turbine Model BYRH UG; Power: 1350 HP; Inlet Steam Pressure: 600 PSI; Steam Temp: 750 F; Exhaust Pressure: 155 PSI. Generator Set is complete with Turbine Gearbox and Generator mounted on steel frame skid.
One (1) used 1.05 MW Elliott Steam Turbine Generators Rebuilt Quantity of Two (2) available. Back Pressure Steam Turbine Model BYRH UG; Power: 1350 HP; Inlet Steam Pressure: 600 PSI; Steam Temp: 750 F; Exhaust Pressure: 155 PSI. Generator Set is complete with Turbine Gearbox and Generator mounted on steel frame skid.
655 kW Steam Turbine with Generator. System includes, Dresser-Rand Coppus RLHA 24 Turbine, Marathon Synchronous Generator, and Lufkin Speed Reducing Gearbox. Year 2013. Turbine Generator Skid: A common steel base is provided for the turbine, speed reducing gear and generator. The turbine and gear are coupled with a Lovejoy flexible stainless steel disc spacer type coupling, dynamically balanced to a maximum 2.5 mm/sec of vibration and meeting ISO G2.5. The generator and gear are coupled with a Lovejoy gear-type coupling with a 1.5 service factor. Coupling guards are installed over both couplings. Skid piping includes all piping necessary to collect condensate drains, steam leak offs and instrument air to single field connection point. Manual globe valves are installed in condensate drain lines for startup condensate removal. Skid wiring includes all conductors and conduit necessary to consolidate terminations for all skid instrumentation and control devices in a common terminal box.
932 HP Elliott Steam Turbine with 655kw WEB Induction Generator. Year 2014. Turbine and Generator are mounted on a steel base frame. Turbine is powered by a Biomass Steam Plant. Steam conditions: 50,000 lb/hr. at 400 PSI / 448F Temperature. Inlet: 400 PSI; Exhaust: 150 PSI; Turbine speed: 3628 RPM.
