Converting Equipment

120” Web Black Clawson Rewinder; 72” Shaftless Rewind, Lowering Table; Speed: 3000 FPM; Shear Slitting; Rewind Diameter: 72”; Black Clawson Shaftless Floor Pick-Up Unwind, 72” Diameter, Year 1989.

Two (2) 60” NDC Scanners, Model 8200, Back-up software disk included. Radioactive source removed. New in 2019 with only sporadic usage since installed. Capable of thickness testing and coating basis weight measurement.

60” Width x 60” Diameter Davis Standard (ER-WE-PA) Turret Unwind; Dual Spindle Turret 3", 6" Core Diameter; Automatic Splicing Unit; With Web Guidance; Dancer System with Potentiometer Feedback Tension Control; Year: 1986/2004 / S/N: 8516-1037.

54” Automatic Splice Drum Surface Winder / Reel; Mfg. Davis Standard (ER-WE-PA). 54” Roll Width x 60” Diameter; 56.5” Drum Width; 36” Drum Diameter; 6” Air Shafts; Auto Shaft Pulling and Loader Accessory. Year: 1986/2004 S/N: 8516-1037.

130" Horizontal Track Reel, Manufactured by GL&V. Dimensions: 129.25" Drum Face, 84" max Roll Diameter. Year 2018 Upgrades: Include New Primary & Secondary Arms for added automation and control. Reel was rebuilt utilizing the existing reel drum, reel bases, and reel doctor. New Primary and Secondary Arms were added with new Pneumatic cylinders and controls and other drive components.

60” Dual Spindle Turret Unwinds; 60” Diameter; Quantity (3); Capacity: 40,000 lbs.; Includes 60” Ultrasonic Flying Splice. Mfg. by Toko; Year 2000. Formerly used for film converting.

60" High Performance Turret Unwind / Rewind Pair, 60" Diameter on Unwind / Rewind. Shaftless design. High speed flying splice. Drives and Controls included. Formerly used in film converting operation.

72” Roll Storage Carousel for 158 Rolls of varying widths and diameters built by Fab-Tech in 2001. Capacity: (158) Carriages with Avg. load of 500 lbs. per carrier. Total weight capacity is 79,000 lbs. with a Max 677 lbs. per carriage. Total (158) Rolls Maximum. Retrieval Time (avg.): 4 minutes 3 seconds. Roll Widths: 48” – 72”; Roll Diameters: 3.5” – 13.75”. Year 2001. Machine Dimensions: 32’-10” H x 26’-5” D x 13' W

36” Wide Six (6) Color Kidder CI Flexographic Press. Features Kidder 649 Updated Drives and Controls Doctor Blades on all decks. Also includes (6) spare Doctor Blade units for quick change over and (6) spare anilox rolls. Has 24” O.D. Turret Unwind and Rewind Overhead Gas Drying and Web Guides on Infeed and Outfeed.

45" Print 47" Web 8-Color Kidder CI Flexographic Press. Totally Upgraded in 2014. All Decks are Doctor Bladed; 24” Diameter Turret Unwind and Rewind; Between Color Drying; Clam Shell Style Gas Burner Overhead Web guide in/out 500 printing sleeves/mandrels; 500+ gears Full Set of 25 Anilox Rolls.

55” Print Width 6-Color PCMC CI (Central Impression) Flexo Press. Chamber Doctor Blade Ink Metering System; 10 DP Gear Pitch. Equipped with Turret Style Unwind and Rewind Designed for 32” Diameter Rolls on 3” Cores 57” Maximum Web Width and a Repeat Range of 12” – 32”. Natural Gas Overhead Dryer. Auxiliary Equipment Included: Edge Guides on In feed and Out Feed 100+ Plate Cylinder Sleeves; 10+ Anilox roll Sleeves; Scan a Web and Bobst Pro Scan 3000 Web Inspection System; Ink Pumps; and Ink Spec Viscosity Controls. Operating Speed of 1200 FPM. Year Manufactured: 1990. Electricals: 460 V / 60hz / 3 PH. Eurotherm Drives. Press no longer in daily production but can be run without printing. Includes all available manuals documentation records and spare parts on hand.

40" Automatic Baler by Maren Model # 72/48-301-OE 40" Deep No Shear Overall Dimensions: 301-1/2" Length x 66" Width x 96-3/4" Height.

60" Wide Baler by Maren Model Excel EX 62 Dimensions: 47" long x 60" wide x 30" height.

58” Standex Rotary Metal Embosser. Standex Engraving Mark 250 SP Rotary Hydraulic Metal Embosser. Designed to Run as Sheet Fed or Continuous operation. 54" Maximum Material Width. Designed for Metal Embossing, Aluminum or Stainless Steel. The Embosser is a Stand-Alone Machine. Manufactured 2015. Like new condition.

90” Web Kusters Embossing Calender 3-Roll Stack. Includes (2) two Kuster S-Roll with engraved embossing patterns one (1) middle position heated tri-pass roll. Rolls have a 102” Face Width and 20” Diameter. Includes hydraulic system and oil heating system and drive motors. Previously used for processing Non-Wovens.

5.8 Meter (228”) Bombi Three-Roll Nonwoven Calender; Type CAL/3C/5.8; 3-Roll; Working width 5800mm; Roll Width 6100mm (240”); Roll Diameter: 800mm (31.5”); Pressure approx. 25 Tons (240 PLI); Oil Heated; Year: 2007.

CLEANSWITCH® RTO Model CS-250 manufactured by Megtec, Capacity 37,000 CFM, Year 2003. Includes New York Blowers, and an on-machine skid mounted control room. Unit has a modular design and is assembled on a steel base frame. Removal and transportation are the buyer’s responsibility. Simple, Modular Design Designed to reduce complexity, the CLEANSWITCH® RTO provides cost benefits with its flexible, modular design. These units are 99% factory assembled for a simple and economical installation. A climate controlled, skid-mounted control room is included for easy access to controls in any type of weather.

62” Width x 50” Diameter Black Clawson Turret Rewinder with Splicing. The rewinder is from a rotogravure coating line now out of operation. Includes Transfer Station for auto splicing.

144" Drum Width Paper machine winder, Black Clawson, 2-Drum slitter rewinder. Roll Diameter: 60"; Operating speed 2500-3000 FPM. Originally manufactured late 1960’s. Previous paper grade was light weight specialty paper.

Quantity (2); Model VAZ 300 / 250 UNF Vecoplan Shredders; 5344-010 Machine Number; Rebuilt “As New” In 2022; Mfg. Year 2001; Rotor: 620mm Diameter; 2491mm Length; Speed: 142 RPM; Main Drive: Electric Motor with Fluid Coupling, Joint Shaft, Two Step Spur; Spur Gear Ratio: 12.5 to 1; Nominal HP: 192 Kw; Nominal Amps: 332A; Motor RPM: 1782; Electricals: 460V / 3 Ph / 60 Hz.
